550W Lamp Waterproof Beam Light DB-LP550
Model：DB-LP550
* High Power Original Osram Sirius 371W/461w Lamp
* 1500 Hours Lamp Life Span
* 540° pan and 270° tilt movement
* 16 bit smooth and precise resolution for PAN/TILT movement
* Scan position memory, auto X/Y reposition Correction
* Beam Angle from 0- 2°
* Color Wheel with 14 colors + Open
* Gobo wheel with 17 Fixed Gobos+Open
* Prism: 8-Facet Circular Prism + 16-Facet Circular Prism with Speed Adjustable and variable direction
* 0-100% Linear Dimmer
* Preset variable/random strobe
* Linear Focus and Variable Frost Filter
* 16 DMX Channels
* Control: DMX 512, Master/Salve, Sound activity & work auto
* -25℃-50℃ Working Temperature
* IP65 Waterproof / IP65 Ture 1 Powercord/ IP65 DMX IN/OUT
* Aluminium and High Temperature Engineering Plastic housing
* Apply for Outdoor Environment such as fountain shows, Theme park, Architectural Shows, Live Concerts, Bridge landscapes etc.
Product Features:
* High Power Original Osram Sirius 550W Lamp
* 1500 Hours Lamp Life Span
* 540° pan and 270° tilt movement
* 16 bit smooth and precise resolution for PAN/TILT movement
* Scan position memory, auto X/Y reposition Correction
* Beam Angle from 0- 2°
* Color Wheel with 14 colors + Open
* Gobo wheel with 17 Fixed Gobos+Open
* Prism: 8-Facet Circular Prism + 16-Facet Circular Prism with Speed Adjustable and variable direction
* 0-100% Linear Dimmer
* Preset variable/random strobe
* Linear Focus and Variable Frost Filter
* 16 DMX Channels
* Control: DMX 512, Master/Salve, Sound activity & work auto
* -25℃-50℃ Working Temperature
* IP65 Waterproof / IP65 Ture 1 Powercord/ IP65 DMX IN/OUT
* Aluminium and High Temperature Engineering Plastic housing
* Apply for Outdoor Environment such as fountain shows, Theme park, Architectural Shows, Live Concerts, Bridge landscapes etc.
Technical Parameters:
| Product Name | Outdoor waterproof Beam 550W moving head light |
| Model | DB-LP550 |
| Input Voltage | AC110-240V, 50-60Hz |
| Power Consumption | 700W |
| Lamp | High Power Original Osram Sirius 550W Lamp |
| Lifespan | 1500 hours, low power consumption |
| Color wheel | 14 colors + Open |
| Fix gobo | 17 fixed gobo+Open |
| Prism | 8-Facet Circular Prism + 16-Facet Circular Prism with Speed |
| Lifespan | 1500 hours, low power consumption |
| Focus | Linear Focus and Variable Frost Filter |
| Usage | Apply for Outdoor Environment such as fountain shows, Theme park, Architectural Shows, Live Concerts, Bridge landscapes etc. |
| Pan/Tilt Movement | 540°Pan movement,270°Tilt movement |
| Strobe | 1-25 times/sec high speed shutter/strobe effect with variable speed; Preset variable/random strobe and dimming pulse effect |
| Dimmer | 0-100% linear LED dimmer |
| Beam Angel | 0-2° |
| Waterproof Rating | IP65 |
| Ambient Temperature | -20℃ ~ 45℃ |
| Net Weight | 42 KG |
| Gross Weight | 44 KG |
| Control Signal | DMX512,Master-slave,Auto,Sound |
| Control Channel | 16 international DMX512 channels |
| Dimensions | 510*420*820mm |
| Packing Size | 660(D)*620(W)*890(H)mm |
