7R 5R Beam Sharpy Moving Head Light DB-MB230
Model：DB-MB230/MB200
* High Power Original 230W 7R Original Philips Lamp
* 1500 Hours Lamp Life Span
* 540° pan and 270° tilt movement
* 16 bit smooth and precise resolution for PAN/TILT movement
* Scan position memory, auto X/Y reposition Correction
* Beam Angle from 0- 3.2°
* Color Wheel with 14 colors + Open
*Gobo1: 17+Open Static Gobo Wheel
* Prism: 8 face Prism with Speed Adjustable and variable direction
* 0-100% Linear Dimmer
* Preset variable/random strobe
* Linear Focus and Variable Frost Filter
* 16/20 DMX Channels
* Control: DMX 512, Master/Salve, Sound activity & work auto
* -25℃-50℃ Working Temperature
* IP20
* Aluminium and High Temperature Engineering Plastic housing
* Apply for nightclub, bar, wedding , Live Concerts etc.
Product Features:
* High Power Original 230W 7R 5R 200W Original Philips Lamp
* 1500 Hours Lamp Life Span
* 540° pan and 270° tilt movement
* 16 bit smooth and precise resolution for PAN/TILT movement
* Scan position memory, auto X/Y reposition Correction
* Beam Angle from 0- 3.2°
* Color Wheel with 14 colors + Open
* Gobo wheel with 17 Fixed Gobos+Open
* Prism: 8-Facet Circular Prism with Speed Adjustable and variable direction
* 0-100% Linear Dimmer
* Preset variable/random strobe
* Linear Focus and Variable Frost Filter
* 16/20 DMX Channels
* Control: DMX 512, Master/Salve, Sound activity & work auto
* -25℃-50℃ Working Temperature
* IP20
* Aluminium and High Temperature Engineering Plastic housing
* Apply for nightclub, bar, wedding , Live Concerts etc.
Technical Parameters:
| Product Name | 7R 230W 5R 20W Beam moving head light |
| Model | DB-MB230/200W |
| Input Voltage | AC90-240V, 50-60Hz |
| Power Consumption | 300W |
| Lamp | High Power Original Osram Sirius 550W Lamp |
| Lifespan | 1500 hours, low power consumption |
| Color wheel | 14 colors + Open |
| Fix gobo | 17 fixed gobo+Open |
| Prism | 8-Facet Circular Prism with Speed |
| Focus | Linear Focus and Variable Frost Filter |
| Pan/Tilt Movement | 540°Pan movement,270°Tilt movement |
| Strobe | 1-25 times/sec high speed shutter/strobe effect with variable speed; Preset variable/random strobe and dimming pulse effect |
| Dimmer | 0-100% linear LED dimmer |
| Beam Angel | 0-3.2° Linear Zoom |
| Waterproof Rating | IP20 |
| Ambient Temperature | -20℃ ~ 45℃ |
| Net Weight | 17 KG |
| Gross Weight | 20 KG |
| Control Signal | DMX512,Master-slave,Auto,Sound |
| Control Channel | 16 /20 international DMX512 channels |
| Dimensions | 402*340*52mm |
| Packing Size | 470(D)*430(W)*560(H)mm |
